Stainless Steel Angle & Channel Manufacturers, Suppliers & Exporters in India

We are a leading manufacturer, supplier, and exporter of high-quality Stainless Steel Angles and Channels in a wide range of grades, sizes, and specifications. Our stainless steel structural sections are manufactured in compliance with ASTM, ASME, DIN, and EN standards, ensuring excellent dimensional accuracy, load-bearing strength, corrosion resistance, and long-term durability. We offer stainless steel angles and channels in popular grades such as SS 304, 304L, 316, 316L, 321, 310, 347, 410, 420, and 904L. These products are extensively used in industries including oil & gas, petrochemical, marine, construction, infrastructure, power generation, and industrial fabrication applications. All stainless steel angles and channels undergo stringent quality inspections and testing to meet national and international standards, ensuring reliable performance in structural and critical engineering applications.

Equivalent Material of Stainless Steel 304H Angle Channels

STANDARD	WERKSTOFF NR.	UNS	JIS
SS 304H	1.4948	S30409	SUS 304H

Chemical Properties Of 304H Stainless Steel Angle Channels

Grade	C	Mn	Si	P	S	Cr	Ni
SS 304H	0.10 max	2.00 max	0.75 max	0.045 max	0.03 max	18 – 20	8 – 10.5

SS 304H Angle & Channels Mechanical Properties

Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2% Offset)	Elongation
SS 304H	8.0 g/cm³	1400 °C (2550 °F)	Psi – 75,000 MPa – 515	Psi – 30,000 MPa – 205	35 %

SS 304H Angle & Channels Mechanical Properties

SS Angle Bar Sizes (mm)	Approx Weight (kg/m)	SS 304H Angle Bar Sizes (mm)	Approx Weight (kg/m)
25 x 25 x 3	1.13	63 x 63 x 8	7.50
25 x 25 x 4	1.46	65 x 65 x 4	4.00
25 x 25 x 5	1.78	65 x 65 x 5	5.02
30 x 30 x 3	1.37	65 x 65 x 8	7.75
30 x 30 x 4	1.78	70 x 70 x 5	5.35
30 x 30 x 5	2.20	70 x 70 x 6	6.40
40 x 40 x 3	1.83	75 x 75 x 6	6.85
40 x 40 x 4	2.41	75 x 75 x 8	9.05
40 x 40 x 5	2.97	80 x 80 x 6	7.35
50 x 50 x 4	3.05	80 x 80 x 8	9.65
50 x 50 x 5	3.78	80 x 80 x 10	11.98
63 x 63 x 4	3.90	100 x 100 x 8	12.20
63 x 63 x 5	3.90	100 x 100 x 12	18.00

Size Chart of Martensitic Stainless Steel 304H L Shape Angle

Size (Inches)	Estimated Weight per Ft. (lbs)	Estimated Weight per 20′ Bar (lbs)
3/4 x 3/4 x 1/8	0.59	11.80
1 x 1 x 1/8	0.80	16.00
1 x 1 x 3/16	1.16	23.20
1 x 1 x 1/4	1.49	29.80
1-1/4 x 1-1/4 x 1/8	1.01	20.20
1-1/4 x 1-1/4 x 3/16	1.48	29.60
1-1/4 x 1-1/4 x 1/4	1.92	38.40
1-1/2 x 1-1/2 x 1/8	1.23	24.60
1-1/2 x 1-1/2 x 3/16	1.80	36.00
1-1/2 x 1-1/2 x 1/4	2.34	46.80
2 x 2 x 1/8	1.65	33.00
2 x 2 x 3/16	2.44	48.80
2 x 2 x 1/4	3.19	63.80
2 x 2 x 3/8	4.70	94.00
2-1/2 x 2-1/2 x 3/16	3.07	61.40
2-1/2 x 2-1/2 x 1/4	4.10	82.00
3 x 3 x 1/4	4.90	98.00
4 x 4 x 1/4	6.60	132.00
4 x 4 x 3/8	9.80	196.00

Dimensions Standard of 304 Stainless Steel U Channel

Description	Process	G (kg/m)	h (mm)	b (mm)	tw (mm)	tf (mm)	r1 (mm)	r2 (mm)
C 50×25×5×6	Hot Rolled	3.95	50	25	5	6	6	3
C 75×40×5×7	Hot Rolled / Laser	6.95	75	40	5	7	8	4
C 100×50×5×7.5	Hot Rolled / Laser	9.37	100	50	5	7.5	8	4
C 125×65×6×8	Hot Rolled / Laser	13.40	125	65	6	8	8	4
C 150×75×6.5×10	Hot Rolled / Laser	18.62	150	75	6.5	10	10	5
C 150×75×9×12.5	Hot Rolled / Laser	24.01	150	75	9	12.5	5	1
C 180×75×7×10.5	Hot Rolled / Laser	21.52	180	75	7	10.5	2	1
C 200×80×7.5×11	Hot Rolled / Laser	24.77	200	80	7.5	11	2	1
C 200×90×8×13.5	Hot Rolled / Laser	30.53	200	90	8	13.5	2	1
C 230×80×8×12	Hot Rolled / Laser	28.56	230	80	8	12	2	1
C 250×90×9×13	Hot Rolled / Laser	34.86	250	90	9	13	2	1
C 250×90×11×14.5	Hot Rolled / Laser	40.34	250	90	11	14.5	2	1
C 300×90×9×12	Hot Rolled / Laser	37.17	300	90	9	12	2	1
C 300×90×10×15.5	Hot Rolled / Laser	43.85	300	90	10	15.5	2	1
C 300×90×12×16	Hot Rolled / Laser	48.78	300	90	12	16	2	1
C 380×100×10.5×16	Hot Rolled / Laser	54.85	380	100	10.5	16	2	1
C 380×100×13×16.5	Hot Rolled / Laser	62.50	380	100	13	16.5	2	1
C 380×100×13×20	Hot Rolled / Laser	67.37	380	100	13	20	2	1

Angle & Channel Application & Uses

SS Angle & Channel Grades

300 Series SS Angles & Channels	SS 301, 302, 303, 304, 304L, 304H, 309, 310, 316, 316L, 316H, 317, 317L, 321, 321H, 347, 347H, 904L
400 Series SS Angles & Channels	SS 409, 410, 410S, 420, 430, 431, 439, 440A, 440B, 440C, 446
Duplex / Super Duplex Angles & Channels	Duplex 2205 (UNS S32205 / S31803), Super Duplex 2507 (UNS S32750), Super Duplex 32760

Stainless Steel Angles & Channels – Approx. Weight Chart

Thickness	Approx. Weight	Thickness	Approx. Weight
(mm)	per metre (kg)	(inch)	per metre (kg)
3.0 mm	2.40	0.118"	2.40
4.0 mm	3.20	0.157"	3.20
5.0 mm	4.00	0.197"	4.00
6.0 mm	4.80	0.236"	4.80
8.0 mm	6.40	0.315"	6.40
10.0 mm	8.00	0.394"	8.00
12.0 mm	9.60	0.472"	9.60

*Weights are indicative and may vary based on angle size, channel section, manufacturing tolerance, and applicable standards.

Stainless Steel Angle & Channel Manufacturers and Suppliers in IndiaSimco Metal Industries

Stainless Steel Angles and Channels manufactured bySimco Metal Industries are widely recognized for their high strength, dimensional accuracy, and excellent corrosion resistance. We are a trusted manufacturer, supplier, and exporter of stainless steel angles and channels in India, catering to construction, fabrication, infrastructure, power plants, refineries, and engineering industries. Our strong logistics network enables timely deliveries across domestic and international markets, with regular dispatches to major Indian ports and overseas destinations.Simco Metal Industries supplies stainless steel angles and channels to Mumbai, Chennai, Surat, New Delhi, Bengaluru, and more than 80+ cities across India. >

The Cities We Supply Stainless Steel Angles & Channels Bengaluru Mumbai Chennai Hyderabad Kolkata Pune New Delhi Ahmedabad Jaipur Surat Salem Gandhinagar Bhiwandi Tiruppur Sivakasi Jamnagar Thiruvananthapuram Rajahmundry Bhubaneswar Vijayawada Firozabad Bokaro Steel City Rajkot Bharuch Panna Raipur Cochin Ludhiana Panipat Durgapur Peenya Pimpri-Chinchwad Channapatna Kharagpur Nashik Bareilly Varanasi Haldia Rourkela Bangalore Moradabad Indore Visakhapatnam Trivandrum Pithampur Dibrugarh Angul Gwalior Coimbatore Kannur Nagpur Vadodara Rudrapur Noida Agra Bhagalpur Jamshedpur Bhilai Lucknow Kanpur Thane Bhopal Sri City Bareilly Hosdurg Pithampur

Other Related Stainless Steel Angle & Channel Products
